Haulotte, has announced a new model for its Pulseo range of all electric aerial work platforms, in the form of a new generation of 61ft HA20E Rough Terrain articulated boom lift.
The new HA20 E and HA20 E Pro, replaces the HA20LE, and shares most of the structural elements with its regular HA20 Rough Terrain models, including a 20.5 metre working height, a maximum outreach of 11.9 metres with 250kg in the platform, or 10 metres with its 350kg maximum, both at an up & over clearance height of 8.5 metres.
The overall dimensions are 8.4 metres long, with an overall width of 2.43 metres and a stowed height of 2.47 metres. With the jib tucked for transport the overall length is reduced to 6.16 metres, but the overall height is increased to 2.98 metres. Total weight is 9,790kg for the regular model, while the four wheel steer and oscillating axle features on the Pro take it up to 9,940kg.
Power comes from a 72 volt/390AH AGM battery pack driving asynchronous electric wheel and pump motors. An optional diesel powered Range Extender unit can be added and removed with a short space of time, effectively converting it to a hybrid, while also offering the capacity to do a full recharge in around three hours. Non-marking rough terrain tyres are standard as is a six degree tilt tolerance for working off level.
The new machines will be launched at Vertikal Days starting on September 10th.
The video below shows a few more details, but to get a real feel – best to visit Vertikal Days.
