Dingli AC+ scissor lifts

Chinese manufacturer Dingli, has introduced a new range slab electric scissor lifts - essentially a major upgrade of its current AC series series - with the first units due off the line shortly.

The new AC+ line up comprises eight models from 19ft to 46ft, with four overall widths - 760mm, 830mm, 1.2 metres and 1.4 metres - with platform capacities ranging from 250kg to 450kg. The nomenclature is also greatly simplified, with the JCPT prefix dropped, so that for example the JCPT1612AC becomes the S1612AC+.
Please register to see all images

The new AC+ range


The new models are
19ft - S0807AC+
20ft - S0808AC+
26ft - S1008AC+
26ft - S1012AC+
33ft - S1212AC+
40ft - S1412AC+
46ft - S1612AC+
46ft - S1614AC+

The chart below shows the key specifications of the new models
Please register to see all images


The AC+ range includes higher platform capacities for each width and height, along with numerous other significant improvements, including electric actuator steering in place of the hydraulic cylinder, leaving platform lift as the only hydraulically operated function on the machine. The new range also comes with what the company describes as a ‘Three-Year Comprehensive Warranty’

The other main improvements include:
- New side and rear fork pockets located at the top of the chassis for improved stability when lifting and moving the machine.
Please register to see all images

Fork pockets side and rear on top of the chassis for improved stability


- A new high capacity lithium iron phosphate battery pack, with a five year warranty.
Please register to see all images

New LFE battery


- A new control box with a high resolution dot matrix display, new silicone function buttons which have endured a 1 million press function test programme.
Please register to see all images

The new controller


- A new non marking tyre compound, from Exmile, that is said to reduce tyre wear by 30 percent, while reducing rolling resistance by six percent.
Please register to see all images

The new tyre


- A new four in one integrated ECU motor controller, which is said to optimise the electric circuit layout and improve output efficiency.
Please register to see all images

The new motor controller


- A more accurate real time load sensing system.
- A gravity driven regenerative lift function, putting power back into the battery pack, and an optional leak containment system.
Please register to see all images

The electric steer cylinder


Please register to see all images

The optional leak containment system


The first units will come off the production line over the next few weeks.

Dingli has a history of regularly upgraded and improving its slab electric scissor lift ranges, moving from hydraulic wheel drive motors to DC electric wheel motors and more recently AC electric wheel drive motors, and now the AC+ series which builds on the AC drive models. At the same time the company has introduced a growing range of ‘Hydraulic oil-free’ models which uses electric actuators to elevate the platform as well as steer, entirely eliminating the hydraulics
